Service Manual
S762A
5
2. INPUT REQUIREMENTS
2.1 Input Power
2.1.1. Power Source 100 ~ 240 Vac, + -10%, 50/60 Hz
2.1.2. Power Consumption
2.1.3. AC Line Drop Out
2.1.4. AC Wave Distortion
2.1.5. In-rush Current
2.1.6. Power Cord
Normal operating mode
Audio function is operating at max output: ≦ 39W
w/o audio function: ≦ 36W
Power saving mode
Audio function is operating at max output: ≦ 7W
w/o audio function: ≦ 2W
Power switch off: ≦ 1W
Picture must not disappear while AC 100 V input drop out(10ms, 100%)
10% max. Permitted
50 A max at 240 Vac cold start
Detachable, 3P with ground type.
2.2 Display Input
2.2.1. Analog Input RGB Video
2.2.1.1 Sync Signal
Analogue, 0.0 to 0.7 V peak to peak
Separate RGB
Input impedance 75 Ohm
Positive polarity
Separate horizontal & vertical sync (3.3V & 5V)
Low level 0.8 V maximum
High level 2.0 V minimum
Positive or negative polarity
Analog Input Connection a. Captive cable length 1.5M in LCD Monitor end, D-sub
male connector in another end.
b. A female Mini D-sub 15 pin base.
