Cub Cadet 1027 User Manual

26
Model 1027
Ref.
No.
Part No. Description
1.
683-0155 Brake Pedal Assembly
2.
683-0156 Variable Pedal Assembly
3.
683-0275 Deck Pedal Assembly
4.
683-0161 Shift Cam Assembly
6.
710-1017 Ab Screw 1/4-14 X .625
7.
711-0701 Clevis Pin
8.
711-1156 Shaft
9.
712-0287 Hex Nut 1/4-20
10.
712-0324 Lock Nut 1/4-20
11.
712-3017 Hex Nut 3/8-16
12.
714-0104 Internal Cotter Pin
13.
714-0111 Hairpin Clip
14.
714-0470 Hairpin Clip
15.
720-0166 Ball Knob
16.
731-0405 Snap-on Bushing
17.
731-1913 Stop Lever
19.
732-0865 Torsion Spring
20.
732-0815 Extension Spring
21.
735-0262 Deck Pad
22.
735-0261 Drive Pad
23.
735-0263 Brake Pad
24.
736-0117 Flat Washer 3/8 X .620 X .033
25.
736-0159 5/16 Washer
26.
736-0169 Lock Washer
27.
736-0187 Flat Washer
28.
736-0272 Flat Washer .510 X 1.00 X .060
29.
736-0133 Flat Washer .406 x 1.25 x .10
30.
736-0329 Lock Washer
31.
736-0608 Spring Washer
32.
736-3000 Flat Washer
33.
736-3019 Flat Washer .531 X 1.062 X .134
34.
736-3020 Flat Washer .271 X .630 X .065
35.
738-0255 Shoulder Screw .375 Dia X .18
36.
738-0373 Shoulder Screw
37.
738-0974 Shoulder Screw .375 X .380 X 1/4-20
38.
741-0591 Flange Bearing
39.
746-0935A Shift Cable
40.
746-0936 Variable Drive Cable
41.
746-0937 Brake Cable
42.
746-0940 Deck Cable
43.
746-0964 Throttle Choke Cable: 67”
44.
747-0963 Brake Rod
45.
747-0964 Brake Lock Out Rod
46.
750-0736 Shoulder Spacer
47.
783-0473 Brake Lock Out Bracket
48.
783-0525 Self-Propelled Pedal Link
49.
726-0450 Plug Cap
50.
783-0593A Shift Lever
51.
783-0794 Bracket: Lock-out Pedal
52.
726-0157 Cable Tie
53.
736-0300 Flat Washer .406 I.D. x .875 O.D.
54.
726-0100 Push Cap
55.
736-0262 Flat Washer
Ref.
No.
Part No. Description

Cub Cadet 1027 Specifications

General

Brand	Cub Cadet
Model	1027
Category	Lawn Mower
Language	English
