35
REF.
NO.
PART
NO. DESCRIPTION
1 618-0375 Variable-speed Bracket Assembly
2 618-0376 Two-speed Transmission Assembly
3 631-0009 Shfter Knob
4 647-0037 Shift Lever
5 656-0050 Variable-speed Pulley Assembly
6 656-0051 Transmission Pulley, 8.5 x .5 - 36
7 683-0251 Double-idler Bracket
8 710-0189 Hex Cap Screw, 5/16-18 x 3
9 710-0227 Self Tapping Screw, #8-18 x .5
10 710-0347 Hex Cap Screw, 3/8-16 x 1.75
11 710-0528 Hex Cap Scerw, 5/16-18 x 1.25
12 710-0778 Self-tapping Screw, 1/4-20 x 1.5
13 710-0604A Self Tapping Screw, 5/16-18 x .625
14 710-3011 Hex Cap Screw, 3/8-16 x 2.25
15 711-0677 Ferrule, 5/16 x .312 Dia.
16 712-0181 Hex Jam Nut, 3/8-16
17 712-0378 Hex Nut, 7/16-20
18 712-0431 Flange Lock Nut, 3/8-16
19 712-0798 Hex Nut, 3/8-16
20 712-3004A Flange Lock Nut, 5/16-18
21 712-3008 Hex Jam Nut, 3/8-16
22 714-0111 Cotter Pin
23 723-3018 Ball Joint, 3/8-24
24 725-1713 Spring Switch
25 726-0320 Insulator Nut Plate
26 732-0384 Extension Spring, .62 Dia. x 6.12
27 732-0716 Extension Spring, .59 OD x 4.0
28 736-0105 Bell Washer, .401 x .870 x .063
29 736-0169 Lock Washer, 3/8
30 736-0275 Flat Washer, 5/16
31 736-0407 Bell Washer, .45 x 1.0 x .062
32 736-0642 Flat Washer, .44 x .75 x .06
33 736-3010 Flat Washer, .407 x .812 x .135
34 738-0322 Shoulder Screw, .625 Dia. x .21
35 747-1122 Brake Rod
36 747-1123A Belt Guard
37 747-1127 Idler Adjustment Rod, 3/8
38 710-1026 Self-tapping Screw, 1/4-20 x 1.75
39 747-1185 Transmission Belt Guard Rod
40 748-0416 Shoulder Spacer, .380 ID
41 754-0467 Variable-speed Belt
42 754-0468 Drive Belt
43 756-0981 Flat Idler, 2.75 OD
44 783-0667 Transmission Torque Bracket
45 783-0669 Idler Bracket
46 647-0031 Brake Control Shaft Assembly
47 647-0032 Speed Control Shaft Assembly
48 683-0266 Drive Pedal Assembly
49 710-1135 Self Tapping Screw, 5/16-18 x 2.5
50 711-0736 Ferrule, 1/4-20
51 711-1363 Pin, 3/8-16 x 2.43
52 714-0104 Cotter Pin
53 732-0437 Compression Spring, .34 OD x 1.0
54 732-0955 Extension Spring, .5 OD x 1.41
55 735-0662 Drive Pedal Pad
56 735-3049 Brake Pedal Pad
57 736-0140 Flat Washer, .281 x .5 x .0625
58 736-0142 Flat Washer, 9/32 x 1/2 x 1/16
59 736-0187 Flat Washer, .64 x 1.24 x .06
60 736-0204 Flat Washer, .344 x .062 x .03
61 738-0155 Shoulder Screw, .437 x 1.62
62 738-0507B Shoulder Screw, .5 x .434
63 741-0225 Hex Flange Bearing
64 741-3065A Split Hex Flange Bearing
65 747-1137 Cruise Control Rod
66 747-1138 Brake Lock Control Rod
67 748-0413 Cruise Latch
68 748-0415A Spacer, 5/16 x 1.54
69 783-0653B Steering Support Bracket
70 783-0732 Drive Lockout Bracket
71 783-0773 Brake Pedal
72 783-0780A Neutral Return Bracket
73 783-0693 Axle Bracket
74 683-0304 Lower Frame Assembly
75 732-0963 Extension Spring, .5 OD x 6.37
76 731-2290 Hub Cap
77 712-3050 Lug Nut, 7/16-14
78 634-0132 Wheel Assembly Complete, 23 x 9.5 x 12
634-0194 Rim Only
734-0255 Air Valve
734-1728 Tire Only, Square Shoulder
79 750-0768 Split Spacer, .25 x .37 x 1.32
80 750-0566 Spacer, .372 x .26 x 1.03
81 712-3026 Jam Nut, 3/4-16
82 736-0316 Flat Washer, .78 x 1.59 x .06
83 710-1260A Hex Screw, 5/16-18 x .75
84 747-1185 Transmission Belt Guard Rod
85 710-0599 Self Tapping Screw,1/4-20 x .5
REF.
NO.
PART
NO. DESCRIPTION
Drive System
