Cub Cadet 1517

-30-
ENGINE CRANKSHAFT & CRANKCASE
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 KH-12 032 03-S Seal, Crankshaft 1
2 KH-12 522 51 Crankcase (Short Block) 1
3 KH-12 445 02-S Strap, Lifting 1
4 KH-M-839025-S Screw, Hex. Flange M8 X 1.25 X 25 1
5 KH-24 380 13-S Pin, Locating 1
6 KH-12 755 49-S Kit, Camshaft (Includes 7, 8) 1
7 KH-12 089 31-S Spring, Actuating 1
8 KH-12 422 08-S Shim, Camshaft - Blue AR
KH-12 422 09-S Shim, Camshaft - Red AR
KH-12 422 10-S Shim, Camshaft - Yellow 1
KH-12 422 11-S Shim, Camshaft - Green AR
KH-12 422 12-S Shim, Camshaft - Gray AR
KH-12 422 13-S Shim, Camshaft - Black AR
KH-12 422 07-S Shim, Camshaft - White AR
9 KH-12 144 27-S Shaft, Balance (Model 1515) 1
KH-12 144 28-S Shaft, Balance (Model 1517) 1
10 KH-12 874 07-S Piston w/ Ring Set (Std.) (Includes 11, 12) 1
KH-12 874 08-S Piston w/ Ring Set (.25) 1
KH-12 874 09-S Piston w/ Ring Set (.50) 1
KH-12 874 11-S Piston w/ Ring Set (.08) 1
11 KH-12 018 02-S Retainer, Piston Pin 1
12 KH-12 108 07-S Ring Set (Std. & .08) 1
KH-12 108 08-S Ring Set (.25) 1
KH-12 108 09-S Ring Set (.50) 1
13 KH-12 067 05-S Connecting Rod (Std.) (Model 1515) 1
KH-12 067 11-S Connecting Rod (Std.) (Model 1517) 1
KH-12 067 06-S Connecting Rod (.25)(Model 1515) 1
KH-12 067 12-S Connecting Rod (Std.) (Model 1517) 1
14 KH-12 380 01-S Pin, Governor Regulating 1
15 KH-12 043 05-S Gear, Governor 1
16 KH-M-631005-S Washer, Plain 6 Mm 1
17 KH-12 144 02-S Shaft, Governor Gear 1
18 KH-52 139 09-S Plug, Cup 1
19 KH-12 755 64-S Kit, Governor Cross Shaft w/clip (Incl. 23) 1
20 KH-X-25-102-S Washer, Plain 1/4” 1
21 KH-12 032 01-S Seal, Governor Cross Shaft 1
22 KH-M-631015-S Washer, Plain 6 Mm 1
23 KH-12 154 05-S Clip, Hitch Pin 1
24 KH-12 041 37-S Crankshaft (Includes 25) (Model 1515) 1
KH-12 041 57-S Crankshaft (Includes 25) (Model 1517) 1
25 KH-12 139 01-S Plug, Cup (Model 1515) 1
KH-12 139 27-S Plug, Cup (Model 1517) 1
