Cub Cadet 1517

-32-
ENGINE OIL PAN & LUBRICATION
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 KH-12 038 01-S Dipstick (Includes 2, 3) 1
2 KH-24 755 46-S Kit, Oil Fill Cap (Includes 3) 1
3 KH-12 153 03-S O-ring 1
4 KH-12 153 02-S O-ring, Upper Oil Fill Tube 1
5 KH-12 123 04-S Tube, Oil Fill 1
6 KH-M-645025-S Screw, Hex. Flange M6 x 1.0 x 25 1
7 KH-12 153 01-S O-ring, Lower Oil Fill Tube 1
8 KH-25 162 07-S Screen, Oil Pickup 1
9 KH-12 096 03-S Cover, Oil Pickup Screen 1
10 KH-M-545016-S Screw, Hex. Flange M5 x 0.8 x 16 1
11 KH-12 050 08-S Filter, Oil 1
12 KH-12 199 50-S Pan, Oil (Includes 13, 16-19) 1
13 KH-25 462 09-S Valve, Oil Pressure Relief 1
14 KH-25 139 52-S Plug, Sq. Hd. 1/8” 1
15 KH-25 139 57-S Plug, Sq. Hd. Solid 3/8” 2
16 KH-12 393 01-S Pump Assembly, Oil 1
17 KH-12 153 06-S O-ring, Oil Pump Cover 1
18 KH-12 096 34-S Cover, Oil Pump 1
19 KH-M-545016-S Screw, Hex. Flange M5 x 0.8 x 16 3
20 KH-12 032 03-S Seal, Oil (P.T.O. End) 1
21 KH-24 086 16-S Screw, Hex. Flange M8 x 1.25 x 45 11
22 KH-24 086 17-S Screw, Hex. Flange M8 x 1.25 x 45 1
