Cub Cadet 1517

-36-
ENGINE IGNITION & ELECTRIC STARTER
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 KH-12 086 14-S Screw, Hex. Flange M10 x 1.5 x 46 1
2 KH-12 468 03-S Washer, Plain 3/8” 1
3 KH-24 162 03-S Screen, Grass 1
4 KH-25 086 47-S Bolt, Shoulder M6 x 1.0 x 16 4
5 KH-12 157 06-S Fan 1
6 KH-X-42-15-S Key 1
7 KH-12 025 15-S Flywheel 1
8 KH-41 403 09-S Rectifier-regulator 1
9 KH-X-22-11-S Washer, Lock 1/4 2
10 KH-M-639016-S Screw, Hex. Flange M6 x 1.0 x 16 2
11 KH-236602-S Connector, Rectifier-regulator (3 Contact) 1
12 KH-41 155 02-S Connector (4 Contact) 1
13 KH-M-548025-S Screw, Hex. Cap M5 x 0.8 x 25 2
14 KH-237878-S Kit, Stator (Includes Terminal 25 452 01-S) 1
15 KH-M-545010-S Screw, Hex. Flange M5 x 0.8 x 10 2
16 KH-X-728-1-S Clip 2
17 KH-12 132 02-S Spark Plug 1
18 KH-M-545020-S Screw, Hex. Flange M5 x 0.8 x 20 2
19 KH-12 584 04-S Module, Ignition 1
20 KH-12 154 06-S Clip 2
21 KH-M-839070-S Screw, Hex. Flange M8 x 1.25 x 70 2
22 KH-12 098 22-S Starter Assembly (Includes 3-8) 1
23 KH-12 755 53-S Kit, Drive 1
24 KH-12 227 19-S Cap, Drive End 1
25 KH-12 070 05-S Armature 1
26 KH-12 221 01-S Brush Assembly 1
27 KH-12 227 13-S Commutator, End Cap 1
28 KH-12 211 01-S Bolt, Thru 2
— KH-25 452 01-S Terminal 2
— KH-X-25-5-S Washer, Plain 1
— KH-12 176 38-S Harness, Wiring 1
— KH-12 518 01-S Lead, White (19” - 18 Guage Fully Insulated 1
Push On Tab And Uninsulated Push On
Terminals)
— KH-24 518 12-S Lead, Black (6” - 12 Guage - Insulated 1
Grip Barrel Eyelet Terminals)
— KH-25 518 05-S Lead, Black (5” - 14 Guage -uninsulated 1
Push On Tab Terminals)
