SPECIFICATIONS
Engine: 18.5HP, 20HP & 22HP Briggs & Stratton
Type: Vertical air cooled V-Twin
Air Cleaner: Paper element
Lube System: Pressurized with oil filter, drain valve with hose
Starter: 12-volt electric
Traction Drive: Engine to two variable-speed integrated hydraulic pump and
wheel motors on each drive wheel
Cutter Deck;Drive: 42”, 44" & 48” belt driven
Clutch: Electric
Deck Lift: Hand lever w/ lock for height adjustment
Cutting Height: 1-1/2" to 4"
No. of Blades 3, belt-driven, power take-off from engine
Controls: Engine ignition and start switch; throttle & choke; left and right
steering levers; electric blade clutch switch; parking brake; mower
deck lift
Parking Brake: Mechanical linkage attached to the brake handle
Front Caster Wheels: 11 x 5.00 - 5
Tire Pressure: 8-10 psi rear, 20-25 psi front caster
Drive Wheels: 18 x 6.50-8 for 42”, 18 x 8.50 - 8 for 44”, 18 x 9.50-8 for 48”
Frame: Structural steel, all welded construction
Seat: Adjustable seat. 4" Adjustment, optional arm rests for 42” & 44”,
standard arm rests for 48”
Fuel Tank: One 5 gallon with shut off valve
Ground Speed: 0-7 MPH forward. 0-3 MPH reverse
Instrumentation: Hour meter
Net Weight: 594 lbs w/42” deck, 598 lbs w/44" deck, 602 lbs w/48” deck
