Operation
5
15
Bagger Usage
NOTE: When both grass bags are full, place the tractor on a firm,
level surface, disengage the PTO, turn the tractor engine off and
set the parking brake.
Flip Seat up.1.
Open the grass bag cover by pushing in on the rear, right-2.
side tab with your right hand, as seen in 1 of Fig. 5-1, and
lifting the cover with your left hand in the center rear of the
bagger cover, 2. Do not remove the chute tube assembly
from the tractor.
Remove the grass bags by lifting these up (1 in Fig. 5-2) and 3.
moving the bags away from the bag support assembly (2).
Figure 5-1
Figure 5-2
Empty the grass clippings at a proper disposal sight, use 4.
the handle at the bottom of each grass bag. Holding the
bag firmly, empty the contents
Replace grass bags, close lid, flip down seat, restart your 5.
tractor and resume cutting your grass.
