17se c t i O n 5 — tw i n re a r ba g g e r pa r t s li s t
Ref. Part Number Description
1. 931-04291 Upper Chute Assembly
2. 931-04292 Double Bagger Cover Assembly
3. 731-06497 Upper Chute Support
4. 731-06504 Bagger Cover Screen
5. 710-0276 Carriage Screw, 5/16-18 x 1.00”
6. 710-3008 Hex Head Screw, 5/16-18 x .75”
7. 711- 03 0 9A Clevis Pin, .62” Dia.
8. 911- 0 4 0 69 Grass-catcher Pin, 1/4-20
9. 711- 0 50 49 Attachment Pin, 1/4 x 0.66 Lg.
10. 711- 0 50 63 Clevis Pin, 5/16 x .75 Lg.
11. 712-04063 Flange Lock Nut, 5/16-18
12. 712-3027 Flange Lock Nut, 1/4-20
13. 714 - 0117 Internal Cotter Pin, .148 x 3.00
14. 714-04040 Bow-Tie Cotter Pin, 72
15. 723-04008A Chute Strap, 6.00 Lg.
16. 731-06099B Bagger Discharge Chute, Elbow
17. 731-06610 Bagger Chute Adapter, 7 In.
18. 732-04510A Torsion Spring Hook
19. 736-0204 Flat Washer, .344 x .62 x .033
20. 736-0176 Flat Washer, .265 x .938 x .120
21. 738-0754 Shoulder Screw, .437 x .54
22. N/A* Mounting Bracket, RH
23. N/A* Universal Mounting Bracket
24. 783-05887-0637 Universal Bracket Support
25. N/A* Mounting Bracket, LH
26. 964-04090A Grass-bag Assembly
27. 683-04461-0637 Double Bag Support Assembly
28. 683-04519-0637 Vertical Support Bracket
29. 711- 0 498 8 Cover Hinge Pin
30. 735-0246A End Plug
31. 689-00101 Mounting Bracket Kit (Incl. ref. 22,
32. 721-04388 Self-Adhesive Foam Strip
*Order Reference 31
To Next Page
