Assembly & Set-Up
3
7
Contents of Carton
• Snow Thrower (1) • Replacement Auger Shear Pins (2) • Chute Assembly (1)
• Chute Control Rod or Flex Shaft (1) • Engine Manual (1) • Product Registration Card (1)
• Snow Thrower Operator’s Manual (1)
There are two chute control styles available that determine your method of assembly. Refer to the image above to determine which
chute control style you have. If your product resembles the image on the left† (above), see page 8 for assembly instructions. If your
product resembles the image on the right (above), see page 10 for assembly instructions.
† 4-Way Chute Control Shown
