Cub Cadet 31AE9P3W710

29
9
Parts List
REF
NO.
PART
NUMBER
DESCRIPTION
1 05244B Housing, Bearing
2 618-0279 Dogg, Steering Drive, LH
3 618-0280 Dogg, Steering Drive, RH
4 618-0282E Shaft Assembly, Steering
5 618-04178 Assembly, Friction Wheel
718-04034 Wheel, Friction, Bonded
710-0896 Screw, Hex Wash
6 684-0118A Bracket, Auger Actuator
7 684-0119A Bracket, Drive Actuator
8 684-04235 Sprocket, 32T
9 684-0161 Arm, Shift
10 684-04212 Brkt, Friction Drive Suprt.
11 684-04103 Rod Assembly, Shift
12 784-0385B Brkt., Idler, Auger
13 710-0538 Screw, Hex Cap Lock,
14 756-0178 Idler, Flat, 2.75 OD
15 754-0222A V-Belt, 1/2 x 44.0
16 750-04718 Spcr., .51 ID x 3.66 Lg.
17 710-1652 Screw, Hex Wash.
18 750-04717 Spcr., .51 ID x 7.895 Lg.
19 710-3001 Screw, Hex Cap, 3/8-16
20 750-04703 Spcr., 1.0 ID x 1.50 OD
21 710-0788 Screw, Hex, 1/4-20 x 1.00
22 710-0459A Screw, 3/8-24 x 1.50
23 711-04279 Shaft, Hex Drive
24 711-04605 Shaft, Actuator
25 716-04048 Ring, Retainer
26 712-0116 Nut, Hex Insert Jam Lock
27 712-0138 Nut, Hex, 1/4-28 GR5
28 784-5726 Bracket, Idler, Drive
29 712-04065 Nut, Hx Flnge Insert Lk
30 712-0413 Nut, Hx Insert Jam Lk
31 710-04484 TT Screw, 5/16-18 x .750
32 712-0717 Nut, Insert 3/8-16
33 713-0284 Chain, Endless, #41 x 36L
34 713-0286 Chain, #420 x 40L
35 713-04015 Sprocket, #41 x 10T
36 714-0135 Key, Woodruff
37 714-0104 Pin, Internal Cotter
38 716-0104 E-Ring
39 714-0388 Key, Hi-Pro, 3/16 x 5/8
40 716-0136 Ring, Retaining
REF
NO.
PART
NUMBER
DESCRIPTION
41 717-0302 Plate, Drive
42 732-0121 Spring, Extension
43 732-0209 Spring, Extension
44 756-0241B Pulley, Dbl, 3.25 OD
45 736-0158 Washer, Lock, 5/8
46 756-0240 Pulley, Flat Idler, 3.0 OD
47 634-0225 Wheel Ass’y. - LH
634-0226 Wheel Ass’y. - RH
734-2031 Tire
734-0255 Valve
741-0246A Bearing
48 711-04615 Pin, Clevis
49 736-0242 Wsh, Bell., .34 x .872 x .06
50 736-0300 Wash, .406 x .875 x .059
51 736-0329 Washer, Lock, 1/4
52 714-0149B Pin, Internal Cotter
53 737-3000 Fitting, Lube, 3/16 Drive
54 738-0143 Screw, Shldr., .498 x .34
55 738-0279 Spindle, Drive Plate
56 738-0924A Screw, Hex Shldr., 1/4-28
57 741-0163A Ass’y, Bearing/Housing
58 741-04108 Bearing, Hex Flange
59 741-04025 Bearing, Self Aligning
60 741-04076 Bearing, Ball
61 741-0563 Bearing, Ball
62 741-0748 Bush, Flg, .5 ID x .627 OD
63 746-0949A Cable, Steering
64 746-0951 Cable, Auger Idler
65 747-0973 Rod, Drive Clutch
66 750-0903B Spcr., .514 x .632 x 2.44
67 750-0997 Spacer, .675 x 1.0 x .23
68 750-1302B Spcr, .6725 x 1.125 x 2.48
69 756-0344 Pulley, Drive
70 756-0625 Roller, Cable
71 790-00257 Cover, Upper Frame
72 790-00259 Cover, Lower Frame
73 711-04606 Axle, Wheel
74 790-00255 Frame, Transmission
75 784-0406A Bracket, Frame Support
76 784-0407 Bracket, Axle Support
77 790-00254 Bracket, Belt Cover
78 710-0191 Screw, 3/8-14 x 1.25 GR8
To order replacement
parts, call the Customer
Dealer Referral Line at
1-877-282-8684,
or visit
www.cubcadet.com to
find the nearest Cub
Cadet service dealer in
your area.
G
E
N
U
I
N
E
F
A
C
T
O
R
Y
P
A
R
T
S
Continued on following page
