Cub Cadet 31AE9P3W710

30
9
Parts List
Model 945 SWE
REF
NO.
PART
NUMBER
DESCRIPTION
79 710-0237 Screw, 5/16-24 x .625
80 710-0607 Screw, Hx Wash Hd Tapp
81 710-1245B Screw, Hx Cap 5/16-24
82 710-0654A Screw, 3/8-16 x 1.00
83 736-0173 Wsh, Flat, .28 x .74 x .063
84 714-0118 Key, Square, 1/4 x 1.5
85 790-00167A Brkt., Belt, Keeper
86 731-2531 Cover, Belt
87 732-0303 Spring, Extension
88 732-0705 Guide, Chute Cable
89 736-0247 Washer, Flat, .406 x 1.25
90 748-0234 Spacer, Shoulder
91 736-0159 Washer, Flat, .349 x .879
92 754-0131 V-Belt, 3/8 x 35.5
93 712-04064 Nut, Flg Lk, 1/4-20
Continued from previous page
