19
6. Lubricate the chute crank spiral gear with a multi-
purpose automotive grease once a year.
7. Lubricate the telescoping square spindle of the
drive shaft (rear half) using 251H EP grease or an
equivalent No. 2 multi-purpose lithium grease
once a year.
8. Lubricate the bearings at each end of the auger
shaft with oil or spray lubricant at least once a sea-
son.
9. Although not necessary, it is advisable to remove
the auger shear pins at least once a season and
spray penetrating oil between the auger tubes and
auger shaft.
OFF-SEASON STORAGE
At the end of the snow season the following steps are
recommended:
1. Remove the snow thrower assembly from the trac-
tor.
2. Wash off any salt deposits which may have dried
on the snow thrower housing. Paint, or cover with
a light coat of oil, any exposed metal surfaces.
3. Lubricate bearings and pivot points with a good
grade of spray lubricant.
4. Store the snow thrower in a dry place.
SECTION VI. ADDITIONAL ACCESSORY REQUIREMENTS
A. WEIGHT KIT MODEL 307
WARNING: The weight kit, Model 307,
must be installed on the rear of the
tractor whenever the snow thrower
attachment is installed on the front of the
tractor. The weight kit must be used with
the proper weights.
1. At all times that the snow thrower is installed on the
front of the tractor, the weight kit must be installed
on the rear of the tractor. The weight kit
counterbalances the weight of the snow thrower
and provides stability to the tractor.
2. Depending upon the prevailing conditions, a
minimum of two suitcase weights and a maximum
of four suitcase weights must be used with the
weight kit.
3. Refer to the weight kit Operator’s Manual for
detailed instructions pertaining to the proper
installation of the weight kit onto the rear of the
tractor.
B. TIRE CHAINS
Tire chains are recommended when using the 42-inch
snow thrower attachment. Tire chains are available at
your authorized Cub Cadet dealer.
