Cub Cadet 6284 Engine Parts Manual

Page 11
Cylinder Block Plate A
A1AH
Item Part No. References Qty. Description Notes
1
Ñ
(LONG ENGINE) 1 CYLINDER BLOCK KIT
2 153-5382 1 PLUG
3 153-5384 2 PLUG
4 153-5381 1 PLUG
5 153-5385 1 PLUG
6 (064400010) 1 CORE PLUG
7 153-5387 4 PLUG
8 221-1136 3 PLUG
9 231-8817 1 BUSH
10 (030500616) 2 DOWEL
11 (030501025) 2 DOWEL
12 153-5390 1 BALL BEARING
13 153-5391 1 PLUG
14 (042303015) 1 BEARING
15 (050209107) 1 REAR OIL SEAL
16 231-8822 1 SHAFT
17 (030500512) 1 DOWEL
18 (010109440) 2 STUD
19 (030309005) 2 PIN
20 (012110635) 1 STUD
21 (012110660) 1 STUD
22 200-6454 1 PLATE
23 215-2618 1 TIMING CASE JOINT
24 (011310612) 2 SCREW
