Page 21
Rocker Shaft Assembly Plate A
B1AH
Item Part No. References Qty. Description Notes
1
231-2184 1 ROCKER SHAFT ASSEMBLY
2 1 ROCKER SHAFT BRACKET
3 231-2183 1 ROCKER ARM SHAFT
4 (015100410) 1 SCREW
5 156-6948 1 PLUG
6 156-6950 1 O RING
7 153-5579 3 LEVER
8 153-5577 3 LEVER
9 153-5586 2 SPRING
10 153-5595 4 WASHER
11 153-5587 6 ADJUSTING SCREW
12 153-5590 6 NUT
13 231-2208 1 ROCKER BOX JOINT
14 153-6861 2 SCREW
15 153-5591 3 STUD
16 153-5592 3 NUT
17 153-5594 6 TAPPET
18 231-2209 6 PUSHROD
