Cub Cadet 6284 Engine Parts Manual

Page 25
Timing Case Plate B
C1LH
Item Part No. References Qty. Description Notes
1 238-1174 1 TIMING GEAR CASE
2 (030300414) 1 PIN
3 231-3821 1 LEVER
4 183-3568 1 SPRING
5 154-1641 1 SPRING
6 154-1401 1 ARM
7 (052100070) 1 O RING
8 (036800008) 1 SNAPRING
9 183-3570 1 LEVER
10 (010110630) 1 SCREW
11 153-5960 1 NUT
12 197-7909 1 SHAFT
13 (052100030) 2 O RING
14 (036800005) 1 CIRCLIP
15 154-1412 1 STAY
16 (011310616) 2 SCREW
17 133-5512 1 NUT
18 158-7936 1 SCREW
19 158-7936 1 SCREW (A)
20 162-2207 1 NUT
21 200-5995 1 SPRING
22 (020700008) 2 NUT
23 238-1266 1 LEVER
24 (026200008) 1 WASHER
25 154-1637 1 ARM
26 (036800006) 1 CIRCLIP
27 (052100050) 1 O RING
28 153-7978 1 FRONT OIL SEAL
29 153-7983 1 PIN
Footnotes
(A) LOW IDLE SETTING

Cub Cadet 6284 Specifications

General

Transmission	Hydrostatic
Drive	2WD
Steering	Power Steering
PTO Speed	540 RPM
Hitch Type	Category 1
Horsepower	28 hp
Brakes	Disc
