Cub Cadet Challenger 700

Engine
4‐47
 Drive Shaft coupling
 Washer
 Nut (1)
Note:
Use the coupling gear/middle shaft tool
(2) to hold the drive shaft coupling.
Nut Torque 97 Nm or 71 ft lbs
Install the middle drive shaft
 Tighten the middle pinion gear nut
(1) to 145 Nm or 107 ft lbs
 Lock the threads with a drift punch.
