Cub Cadet GT 2186 User Manual

-11-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 618-04115 Hub Assembly, Wheel 2
2 618-3060 Plate Assembly, Brake 1
3 619-0056 Axle Housing, RH 1
4 619-0057 Axle Housing, LH 1
5 719-04078
759-3746
Transmission Housing, RH
Sealant, Ultra Grey
1
6 719-04077 Transmission Housing, LH 1
7 703-2191 Brake Arm 1
8 710-0606 Screw, Hex Cap, 1/4-20 x 1.5 2
9 710-0788 Screw, Hex Wash Hd Tap, 1/4-20 x 1.0 13
10 721-3029 Seal, Shift Shaft 1
11 710-1008 Screw, TT, 3/8-16 x 1.875 8
12 710-1633 Screw, Plug, M14 x 1.5 x .827 1
13 710-3144 Screw, Hex Cap, 3/8-16 x 2.0 GR5 4
14 710-3262 Screw, Cap, 3/8-16 x .750 1
15 711-1052A Shaft, Cross, .500 x 3.005 2
16 711-04164 Shaft, Axle, 1.00 x 12.07 1
17 711-04211 Shaft, Axle, 1.00 x 15.73 1
18 711-04210 Shaft, Drive 1
19 711-04209 Shaft, Intermediate 1
20 712-0291 Nut, Hex Center Lock, 1/4-20 2
21 712-3020 Nut, Hex Insert Lock, 3/8-16 GR5 4
22 715-3045 Dowel Bushing 6
23 716-04032 Ring, Retaining, .938 4
24 716-0204 Ring, Retaining, 2
25 717-1446 Gear, Miter, 10T 4
26 717-04102 Gear, Miter, 14T 2
27 717-1568 Gear, Differential Spur, 60T 1
28 717-3346 Shaft, Output, 9T 1
29 717-3347 Gear, Bevel, 36T 1
30 717-04111 Gear, Spur, 18T 1
31 717-3388 Gear, Spur, 27T 1
32 717-3391 Gear, Spur, 16T 1
33 717-3392 Gear, Spur, 42T 1
34 719-0375A Housing, Differential, RH 2
35 721-04031 Seal, Oil, 1.0 x 1.499 2
36 727-3085 Dipsick, Oil 1
37 732-0152 Spring, Compression 1
38 732-3077 Spring, Brake Shoe 1
39 736-0463 Washer, Flat, .25 x .630 x .0515 4
40 741-0361 Bearing, Ball, 17 ID x 40 OD x 12 3
41 741-3057 Bearing, Ball, 6204 3
42 741-3114 Bearing, Ball, 6205-1 2
43 761-3019 Drum, Brake 1
44 761-3020 Brake, Shoe 2
45 761-3028 Brake, Actuator 1
46 736-0745 Washer, Flat, 1.010 x .56 x .060 2
47 710-3119 Screw, Hex Lock, 3/8-16 x .75 GR5 2
48 736-0227 Washer, Flat, .39 x 1.5 x 1.34 2
49 741-0681 Bearing, Ball 2
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
HYDRO TRANSMISSION
