Throttle/Choke Control
The throttle/choke control is located on the left side of
of the engine and, when pushed all the way forward,
closes the choke for cold starting. When set in a given
position, the throttle will maintain a uniform engine
speed.
NOTE: When operating the tractor with the cutting
deck engaged, be certain that the throttle/choke
Brake Pedal
The brake pedal is located on the right
front side of the tractor above the drive
pedal along the running board. The
brake pedal can be used for sudden
stops or setting the parking brake.
NOTE: The brake pedal must be fully
depressed to activate the safety
interlock switch when starting the tractor.
Seat Adjustment Lever (Not Seen)
The seat adjustment lever is located below the front/left of the
seat. The lever allows for adjustment of the fore to aft position of
this manual for more detailed instructions.
Ignition Switch Module
WARNING! Never
leave a running
machine unattended.
Always disengage
engine and remove key to prevent
unintended starting.
To start the engine, insert the key
into the ignition switch and turn
clockwise to the position.
Release the key into the
position once the
engine has fired.
To stop the engine, turn the ignition key counterclockwise to the
position.
CAUTION:
Module and operating the tractor in
.
Drive Pedal
The drive pedal is located on the right side of the
portion of the drive pedal forward to cause the
tractor to travel forward. The further forward the
pedal is pivoted, the faster the tractor will travel.
The pedal will return to its original position when
Reverse Pedal
The reverse pedal is located on the right side of the
portion of the reverse pedal with the ball of your
travel in reverse. The further rearward that the
pedal is pivoted, the faster the tractor will travel.
The pedal will return to its original position when
Systems Indicator Monitor/
Hour Meter LCD
When the ignition key is rotated out of
position, the systems indicator monitor
LCD for approximately five seconds, after
which it displays an hour glass and the hours of tractor operation.
hour glass and the hours of tractor operation on its LCD.
NOTE:
whether the engine is started.
The Indicator Monitor will also remind the operator of
maintenance intervals for changing the engine oil. The LCD will
HOURS 1/10
PTO
/
B
L
A
D
E
PA
R
K
B
R
A
K
E
O
I
L
BAT
T.
13se c t i O n 4 — cO n t r O l s a n d fe a t u r e s
