Deck Rear Roller Adjustment
The rear rollers on the mower deck are not designed to carry
the weight of the deck. The rear rollers should be adjusted to
approximately ⁄⁄
moved to the desired cutting height.

desired cutting height, and check the height of the rear rollers. If
contacting the ground, or above ⁄
rear rollers as follows:
The deck roller assembly index bracket has five adjustment
positions holes.
While supporting the roller assembly, remove click pin and 
withdraw the clevis pin from both the left and right roller

2.
approximately ⁄⁄
Align the nearest index bracket holes with the holes in the 
deck mounting brackets. Insert the clevis pins through the
deck brackets and the index brackets and secure with the

NOTE: The clevis pins should be in the corresponding holes of
both the left and right roller index brackets.
Index Bracket
Clevis Pin
Click Pin
Figure 6-8
24 se c t i O n 6 — Ma i n t e n a n c e & ad j u s t M e n t s
