-15-
For Choke
ENGINE ACCESSORIES
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0227 Screw, #8-18, 0.500 4
2 710-0599 Screw, Self-tapping, 1/4-20, 0.500 4
3 710-0726 Screw, Hx. Wash. Hd. Tapp 5/16-12 x .75 2
4 710-1315 Screw, Hx. Wash. Hd. Tapp 3/8-16 x 4
5 712-3005 Nut, Hex Flange Lock, 3/8-16, Gr5 1
6 725-0157 Cable, Tie, 3/16 x .05 x 7.4 2
7 726-0205 Clamp, Hose, .490 Dia. 4
8 736-0300 Washer, Flat, .406 x .875 x .059 1
9 751-0535 Hose, Fuel Line 45 in
10 751-0564A Deflector, Muffler 1
11 751-0644B Pipe, Exhaust, LH 1
12 751-0645A Pipe, Exhaust, RH 1
13 751-0805 Muffler, Dual Inlet 1
14 751-3140 Drain, Oil 1
15 751-3141 Hose, Extension, Oil Drain 12in
16 751-3142 Cap, Oil, Drain 1
17 783-0615D Shield, Heat, Muffler 1
18 726-0154 Tie, Cable, Push Mount 7.5 Lg 3
19 712-3086 Nut, M8, 1.25 2
20 KH-24-041-02 Gasket, Exhaust 2
8
1
20
17
2
3
4
5
19
19
7
14
16
15
11
12
13
10
20
6
9
7
7
7
9
18
