Cub Cadet GT1554 Parts Manual

-17-
DASH PANEL
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0192 Screw, #10-24 X .375 2
2 710-04187 Screw, Hx. Wash Hd. 1/4-15 x .5 1
3 710-0599 Screw, Self-tapping, 1/4-20, 0.500 6
4 710-0642 Screw, Hx. Wash. Hd, Tapp. 1/4-20 x .75 2
5 710-0726 Screw, Hx. Wash. Hd, Tapp, 5/16-12 x .75 12
6 710-0837 Screw, Oval Cntrsnk, #10-16 x .625 1
7 710-0895 Screw, 1/4-15, 0.750 2
8 710-1611B Screw, Torx Hd. Tapp. 5/16-18 x .75 2
9 710-04471 Screw, Ball, 5/16-18 2
10 710-3217 Screw, Truss Mach., #8-32 x .375 1
11 712-0142 Nut, Hex, #8-32 GrA 1
12 712-0324 Nut, Hex Insert Lock, 1/4-20 GR8 1
13 712-3004A Nut, Hex Flange Lock, 5/16-18 GR5 2
14 714-0104 Internal Cotter Pin, .072 x 1.13 1
15 727-3194 Cylinder, Gas 2
16 731-04293A Lever, Dash, Brake 1
17 731-04294A Lever, Dash, Cruise 1
18 731-05077
777I22459
Dash
Graphic, Dash Insert
1
1
19 731-3161 Knob, Throttle Control 1
20 736-0300 Washer, Flat, .406 x .875 x .059 2
21 736-0362 Washer, Flat, .33 x 1.25 x .06 HT 2
22 741-0587 Bearing, Steering Column 1
23 747-04215 Strap, Batter 1
24 747-1323A Rod, .25 x 4.55 1
25 783-04285B Plate, Dash Support RH 1
26 783-04323B Plate, Dash Support, LH 1
27 783-04475 Bracket, Steering Support 1
28 783-04506A Plate, Dash Support 1
29 783-0462 Bracket, PTO Switch Retainer 1
30 783-1447A Bracket, Support, Battery 1
31 783-1499 Bracket, Rod, Dash 1
32 746-1100 Cable, Throttle, 38.0 Lg 1
33 746-04120 Cable, Choke, 40.5 Lg. 1
34 925-1707D Battery, 235 CCA, Dry 1
35 710-0703 Screw, Carriage, 1/4-20, .75, 1
36 712-0271 Nut, Hex, 1/4-20, Sems 1
37 712-3087 Nut, Wing, 1/4-20 1
38 738-1132 Screw, Shoulder, 1/4-20, .25 x .15 1

Cub Cadet GT1554 Specifications

General

Engine Brand	Kohler
Transmission	Hydrostatic
Drive	2WD
Deck Material	Steel
Engine Type	4-Cycle
