-23-
54 INCH MOWER DECK
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 12650 Bracket, Height Adjustment 22
2 16606 Bracket, Hook, Retainer 1
3 918-04217
737-3000
Housing Ass’y., Spindle
Fitting, Lube, 3/16 Drive
3
3
4 683-0254B Bracket, Deck Hanger, LH 1
5 683-04113A
777S30015
777S30503
777I22265
777D08336
777D07875
Deck Housing Ass’y.
Graphic, Danger
Graphic, Danger
Graphic, Belt Routing
Graphic, Deck Wash
Graphic, 54 Inch
1
1
1
1
1
1
6 683-0459 Arm, Idler 1
7 703-2093 Baffle, Rear Inner 1
8 703-3279 Bracket, Chute Stop 1
9 710-0216 Screw, Hex Cap, 3/8-16 x .75 GR5 2
10 710-0520 Screw, Hex Cap, 3/8-16 x 1.5 GR5 1
11 710-0521 Screw, Hex Cap, 3/8-16 x 3.0 GR8 1
12 710-0528 Screw, 5/16-18, 1.25, Gr5 1
13 710-0599 Screw, Hx. Wash. Hd.Tapp 1/4-20 x .5 1
14 710-0623 Screw, Hx. Wash.Hd. Tapp,
3/8-16 x .75
4
15 710-0726 Screw, Hx. Wash. Hd. Tapp,
5/16-12 x .75
19
16 710-1260A Screw, Hex Wash. Hd Tapp
5/16-18 x .75
12
17 710-3103 Screw, Hex Cap, 5/16-18 x 2.0 Gr5 1
18 710-3168 Screw, Carriage, 3/8-16 x 1.0 1
19 710-3178 Screw, Carriage, 3/8-16 x .75 2
20 711-0332 Pin, Clevis, .5 x .78 2
21 711-1737 Roller Pin 1/2" x 10.06 Lg 1
22 712-0229 Nut, Push, 3/8 2
23 712-04063 Nut, Flange Insert Lock, 5/16-18, GrF 1
24 712-04065 Nut, Flange Insert Lock, 3/8-16, GrF 7
25 712-0431 Nut, Hx. Flange Lock, 3/8-16 GrF 2
26 712-0641 Nut, Hex, M16-1.5 2
27 712-3010 Nut, Hex, 5/16-18 GR5 1
28 712-3022 Nut, Hex Lock, 1/2-13 GrB 1
29 714-0111 Pin, Cotter, 3/32 x 1.0 1
30 714-0145 Pin, Internal Cotter 2
31 714-0162 Pin, Cotter, 5/32 x 1.25 2
32 714-0470 Pin, Cotter, 1/8 x 1.25 2
33 715-0108 Pin, Spring, 1/4 x 1.0 2
34 717-04074 Gear, Deck Adjustment 1
35 721-04041 Adapter, Water Nozzle 1
36 731-0335 Roller, Deck 4
37 731-3005 Front Roller 1
38 732-0306A Spring, Compression, .531 x 1.75 Lg 2
39 732-0459B Spring, Extension, .94 x 6.74 1
40 732-0934 Spring, Extension, 1.15 x 5.99 1
41 734-04039 Wheel, Gauge 2
42 736-0119 Washer, Lock, 5/16, Regular Duty 1
43 736-0300 Washer, Flat, 0406 x .875 x .059 2
44 736-0760 Washer, Lock 2
45 736-0921 Washer, Lock , 1/2 1
46 737-04003B Nozzle, Deck Wash 2
47 738-0295 Shaft, .75 x 47.12 1
48 738-0373 Shoulder Screw, .498 x 1.53:3/8-16 2
49 738-1229A Shoulder Screw, .625 x 2.5:1/2-13 1
50 759-3820 Blade, Hi-Lift Mower, 18.5 3
51 747-1116 Rod, Handle, Deck Release .375 Dia 2
52 750-0151 Spacer, .55 x .755 x 1.1 2
53 750-0212 Spacer, .82 x 1.0 x .53 2
54 750-0748 Spacer, 3/8 x 1.0 x 1.25 1
55 754-04083 Belt, V, B Sect 136.0 1
56 756-04129 Pulley, Idler, 4.25 Dia. 2
57 783-04013A Bracket, Pulley Stabilizer 1
58 783-04462 Bracket, Lift 1
59 783-04690 Skirt, Deck 2
60 783-04726 Bracket, Idler Pulley 1
61 783-1470 Cover, Spindle RH 1
62 783-1471 Cover, Spindle LH 1
63 631-04070
711-1762
732-3070
783-04470
777S30145
Chute Assembly
Pin, Hinge, .375 Dia x 14.06
Spring, Torsion
Bracket, Mounting
Graphic, Danger
1
1
1
1
1
64 710-04224 Bolt, Spindle, 3/4-16 x 7.16 3
65 756-3096 Pulley, Spindle 3
66 748-3101 Spacer, Blade 6
67 750-0952 Spacer, .792 x 1.06 x 1.8 3
68 748-3065 Spacer, Deck Spindle 6
69 712-3078 Nut, Hex Flange, 3/4-16 3
70 721-3018A Seal, Oil, Single Lip 6
71 741-04129 Bearing, Cone 6
72 741-04130 Cup, Bearing 6
73 750-3190A Spacer, Bearing, .780 x 1.000 x 3
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
