-25-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 HG-70297 Main Housing, Assembly 1
2 HG-70298 Housing, Assembly, RH 1
3 HG-70683 Center Section, Assembly 1
4 HG-2003018 Spacer 1
5 HG-900800-0128 Seal, Lip 1
6 HG-2003016 Wire Retaining Ring 1
7 HG-2003052 Retaining Ring 1
8 HG-2003043 Ball Bearing 1
10 HG-2003087 Variable Swashplate 1
11 HG-50551 Thrust Bearing 1
12 HG-50795 Input Shaft 1
13 HG-2003017 Block Thrust Washer 1
14 HG-2003014 Block Spring 1
15 HG-70331 10cc Cylinder Block Assembly 1
21 HG-70082 21cc Cylinder Block Assembly 1
24 HG-50662 Output (Motor) Shaft 1
25 HG-50552 Thrust Bearing 1
26 HG-51125 Control Arm 1
27 HG-50774 Spacer 1
28 HG-50661 16T Pinion Gear 1
29 HG-50975 Capscrew, M6 x 1-25 2
30 HG-2000015 Slot Guide 1
31 HG-50807 Trunnion Arm 1
32 HG-2003009 Trunnion Bushing 1
33 HG-9008000-0126 Lip Seal 1
34 HG-51127 Return Arm 1
38 HG-70680 Kit, Bypass Plate 1
39 HG-2003555 Bypass Actuator 1
40 HG-45074 Lip Seal 1
41 HG-50270 Bypass Arm 1
42 HG-44870 Retaining Ring 1
43 HG-50002 Pin 2
44 HG-50016 Screw 3
46 HG-51153 Return Spring 1
48 HG-51097 Adjusting Puck 1
50 HG-50752 Screw, 1/4-20 x .75 11
51 HG-50972 Lower Cover 1
52 HG-50273 Gerotor Assembly 1
53 HG-9004101-1340 Base, Filter 1
54 HG-50260 Gerotor Cover 1
55 HG-70538 Kit, Filter 1
56 HG-51156 Charge Manifold 1
57 HG-50796 Retainer, Motor Bearing 1
58 HG-50776 Pin, Carrier 4
59 HG-50763 15T Planet Gear 4
60 HG-50646 67T Spur Gear 1
61 HG-50645 21T Sun Gear 1
62 HG-50769 Planet Thrust Plate 1
63 HG-50764 51T Ring Gear 1
64 HG-50765 Planetary Carrier 1
65 HG-50647 Miter Gear, Diff. (Splined) 2
66 HG-50648 Miter Gear, Diff. 2
67 HG-50766 Shaft, Differential 1
68 HG-50767 Differential Thrust Plate 1
69 HG-50768 Flange Bearing 2
71 HG-50788 Washer, 1.0 x 2.25 x .04 3
73 HG-50791 Hex Jam Nut, 5/8-18 2
74 HG-50771 Ball Bearing 2
75 HG-50772 Seal, 1” ID x 2.0472 x .375 2
76 HG-50825 Shaft, Axle 2
77 HG-44130 Washer 1
80 HG-50868 Torx Head Screw, 5/16-18 8
81 HG-44752 Needle Bearing 1
82 HG-50777 Washer 2
83 HG-50775 Retaining Ring 1
84 HG-50773 Lip Seal 1
85 HG-50779 Brake Disk 1
86 HG-50132 Washer, .5 x 1.0 x .03 1
87 HG-50836 Washer 1
88 HG-50837 Screw, 5/16-24 x 1-1/2 1
89 HG-44147 Ball Bearing .62 ID x 1.38 x .44 1
90 HG-51200 Spacer, Locating 1
92 HG-50870 Countersunk Screw 1
95 HG-50108 Hex Lock Nut, 5/16-24 1
96 HG-50866 Sleeve Bearing 1
102 HG-50813 Torque Bracket 1
103 HG-50818 Pulley 1
104 HG-50848 Fan 1
106 HG-50850 Spacer, Trunnion 1
107 HG-50851 Screw 3
109 HG-50133 Bushing, Rubber 1
110 HG-70302 Fitting Kit 1
111 HG-70109 Cap, Vent Assembly 1
113 HG-70301 Hose/Fitting Assembly 1
115 HG-44133 Hex Nut, 1/2-20 1
116 HG-50859 Retaining Ring 2
117 HG-9004800-2506 Std. Hdls. Pin 2
118 HG-70276 Hub Assembly 2
119 HG-50863 Nut, Hex, 3/4-16 2
120 HG-44132 Puck, Brake 2
121 HG-50874 Rib Neck Bolt, 2” 1
122 HG-70633 Yoke, Brake Assembly 1
124 HG-50936 Arm, Brake 1
125 HG-44127 Pin, Brake 2
126 HG-43177 Lockwasher, 1/4 2
127 HG-43178 Nut, 1/4-20 2
128 HG-44142 Nut, Castle 1
129 HG-44101 Cotter Pin 1
130 HG-23711 Spacer 1
131 HG-44134 Puck Plate 1
132 HG-50865 Rib Neck Bolt, 3” 1
133 HG-50869 Wheel Stud, 7/16-14 8
136 HG-50384 Extension Spring 1
137 HG-50882 Spring Pin 1
138 HG-50653 Screw 1
139 HG-44278 Washer, 7/8 x .265 x .125 1
141 HG-50884 Spring, Brake Arm Bias 1
142 HG-43064 Hex Lock Nut, 5/16-18 1
143 HG-50886 Bolt, 5/16-18 x 2.5 1
144 HG-50974 O-Ring 1
145 HG-51157 Spring, Relief 1
146 HG-9001214-4400 Ball 1
151 HG-50919 Comp. Spring, Brake Anti-Drag 1
153 HG-9005110-5600 Plug 1
154 HG-50920 Wire Retaining Ring 1
155 HG-70311 Fan/Pulley Assembly Kit 1
157 HG-50977 O-Ring 4
168 HG-51151 Shouldered Torx Hd. Screw, 5/16-18 1
HG-50928 Sealant 1
HG-70492 Kit, Seal 1
122 0z. Oil- 20W50
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
HYDROSTATIC TRANSMISSION
