Cub Cadet GT1554 Parts Manual

-5-
DRIVE SYSTEM
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 618-0379 Transmission, Hydro 1
2 629-04143
629-0949A
Harness, Rev 14AK13CK710
Harness, Rev 14AK13CK709
1
1
3 710-0176 Screw, Hex Cap, 5/16-18 x 2.75 GR5 4
4 710-0216 Screw, Hex Cap, 3/8-16 x .75 GR5 2
5 710-0227 Screw, Hex Wash Hd Tapp, #8-18 x .5 2
6 710-0344 Hex Cap Screw, 3/8-16 x 1.5, GR5 1
7 710-0599 Screw, Hx Wash Hd Tapp, 1/4-20 x .5 1
8 710-0726 Screw, Hx Wash Hd Tapp, 5/16-12 x .75 6
9 710-1007 Screw, Hx Wash Hd Sems Tapp
3/8-16 x 1.5
2
10 710-3011 Hex Cap Screw, 3/8-16 x 2.25, Gr5 1
11 711-0832 Ferrule, 3/8-24 x .375 Dia 1
12 712-04063 Nut, Flange Insert Lock, 5/16-18 GrF 4
13 712-04065 Nut, Flange Insert Lock, 3/8-16 GrF 3
14 712-3017 Nut, Hex, 3/8-16, GR5 2
15 714-0104 Pin, Cotter, .072 Dia. x 1.13 Lg 2
16 714-0111 Pin, Cotter, 3/32, 1.0 2
17 725-0157 Cable, Tie, 3/16 x .05 x 7.4 2
18 725-1644 Switch, Spring, Short 1
19 726-0154 Tie, Cable, Push Mount 7.5 Lg 1
20 726-0320 Plate, Insulator Nut 1
21 732-0429A Spring, Extension, .50 Dia x 3.97 Lg 1
22 732-0716 Spring, Extension, .59 OD x 4.00 Lg 1
23 732-3118 Spring, Extension, 3/8 OD x 1.44 Lg 1
24 736-0169 Washer, Lock, 3/8 , Regular Duty 1
25 736-0320 Washer, Flat, .38 x 1.38 x .125 1
26 736-3010 Washer, Flat, .407 x .812 x .135 Hdn 1
27 738-0372B Spacer, Shoulder, 1.00 x .38 x .38 1
28 747-04140 Rod, Brake, LT 1
29 747-1119 Rod, Hydro Control 1
30 747-1121 Rod, Hydro Disengage 1
31 750-0535 Spacer, .376 ID x .625 OD x .22 1
32 754-0349 Belt, V Type A, 79.10 Lg 1
33 756-0116A Pulley, Idler, V Type x 3.06 Dia 2
34 756-0981B Pulley, Idler, Flat 2.75 OD 1
35 783-04442 Bracket, Idler 1
36 783-0667B Bracket, Transmission Torq 1
37 783-0745 Bracket, Speed Control 1
38 783-0782 Bracket, Actuator 1
