Cutting Deck Removal
To remove the cutting deck, proceed as follows:

position and engage the parking brake.
Lower the deck by moving the deck lift lever into the 2.
bottom notch on the right fender.


Looking at the cutting deck from the left side of the tractor, 4.
locate the deck support pin on the rear left side of the
deck.
5.

6.
Move the deck lift lever into the top notch to raise the deck 7.
lift arms up and out of the way.
Remove the cotter pin from the end of the stabilizer rod 8.
and slide the stabilizer out of the hanger bracket on the
deck. See Fig. 7-2.
Gently slide the cutting deck (from the right side) out from 9.
underneath the tractor.
Figure 7-1
Figure 7-2
Service
7
24

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cub Cadet LTX 1046 and is the answer not in the manual?

Cub Cadet LTX 1046 Specifications

General IconGeneral
Horsepower22 HP
Cutting Width46 inches
TransmissionHydrostatic
Deck MaterialSteel
Engine Displacement725 cc
Cylinders2
Cutting Height1.5 - 4 inches
Number of Blades2
Turning Radius18 inches
Front Tires15 x 6 inches
Rear Tires20 x 8 inches
Engine Power22 HP
Speed5.5 mph
EngineKohler Courage
Engine TypeFour-Cycle
Blade EngagementManual
Warranty3 years limited
