Cub Cadet LTX1042 User Manual

Remove the cotter pin from the end of the stabilizer rod 
and slide the stabilizer out of the hanger bracket on the

Gently slide the cutting deck (from the right side) out from  
underneath the tractor.
Changing the Deck Belt
WARNING! The V-belts found on your tractor are
specially designed to engage and disengage safely.

not disengaging completely. For a proper working
machine, use factory approved belts.
All belts on your tractor are subject to wear and should be
replaced if any signs of wear are present. To change or replace
the deck belt on your tractor, proceed as follows:
Remove the deck as instructed on page 24.
Remove the belt covers by removing the hex washer 2.

6.

7.
Move the deck lift lever into the top notch to raise the deck 8.
lift arms up and out of the way.
Carefully remove the deck engage cable from the rear of 
the cutting deck by removing the bow-tie cotter clip that
secures it. Remove the spring from the deck idler bracket.

Deck Lift
Arm
Deck Support
Pin
Figure 7-3
Figure 7-5
Figure 7-4
Hex Washer Screws
Belt Cover
Deck Idler Pulley
Spindle Pulley
Belt Guard
Figure 7-6
25se c t i O n 7 — se r v i c e

Cub Cadet LTX1042 Specifications

General

Engine Brand	Kohler
Engine Model	Courage
Cylinders	1
Cutting Width	42 inches
Cutting Height	1.5 - 4 inches
Transmission Type	Hydrostatic
Blades	2
Deck Material	Steel
Turning Radius	18 inches
Front Tires	15 x 6 in
Rear Tires	20 x 8 in
Warranty	3-year limited
