10 Section 3— Set-Up
Manually Moving the Rider
1. Engage the transmission bypass rods, one on each side of
the rider, to move the rider manually without starting it.
The transmission bypass rods are located on the rear of the
rider, just inside each rear wheel. Engage the bypass rods
by pulling each one out (a) and to the right (b) to lock it into
place. See Figure 3-3.
Figure 3-3
2. Disengage the bypass rods by reversing steps a & b after
moving the rider. See Figure 3-3.
3. Remove the deck wash system nozzle adapter from the
manual bag and store for future use.
Charging the Batteries
CALIFORNIA PROPOSITION 65 WARNING!
Battery posts, terminals, and related accessories
contain lead and lead compounds, chemicals known
to the State of California to cause cancer and
reproductive harm. Wash hands after handling.
WARNING: The batteries contain corrosive fluid
and toxic material — HANDLE WITH CARE. Keep
away from children. Do not puncture, disassemble,
mutilate, or incinerate. Explosive gases could be
vented during charging or discharging. Charge in a
well ventilated area, away from sources of ignition.
WARNING! Recharge only with the charger
provided with this rider. A charger that is not
suitable for this machine may damage the batteries
or create the risk of fire.
WARNING! Do not charge or operate the rider in the
rain or in wet conditions.
NOTE: The batteries in your rider are not expected to last for
the life of your rider. Rechargeable batteries degrade with time
and use. The batteries may eventually need to be replaced. To
have the batteries replaced, contact your authorized Cub Cadet
Service Dealer.
Refer to the manual packed with your battery charger for
information and instructions on charging the batteries. Refer to
the Controls & Features section of this manual for the location of
the charging port on the rider.
NOTE: Use only the battery charger provided with this rider.
NOTE: The batteries should be fully charged before the initial use.
NOTE: Never charge a frozen battery.
NOTE: It is recommended that the rider be charged once every
month during off-season storage.
NOTE: Always disconnect battery charger (or extension cord,
if used) from the electrical outlet first, then disconnect battery
charger from the charging port.
NOTE: It is recommended that the batteries be fully charged
after each use. Storing batteries in a discharged state could
reduce future performance.
NOTE: It is recommended that the uit be plugged in at all times
when not in use.
LCD Display
The language and measurements can be changed while the
rider is on by pressing the “BLADE NORMAL” button below the
icon. To set the language, press the “BLADE NORMAL” button
until the desired langauge is displayed. To change the language
and measurement, press the “SYSTEM SETTINGS” button below
the icon. When the menu comes up, press the “BLADE
BOOST” button below the icon to change the measurements,
to change the language press the “BLADE NORMAL” button
below the icon. To go back to the home screen, press the
“SYSTEM SETTINGS” button below the icon.
