Set-Up
3
9
Contents of Crate
• One Rider • One Battery Charger • One Deck Wash Hose Coupler
• One Rider Operator’s Manual • One Battery Charger Manual
Rider Preparation
Steering Wheel Column
Place the steering column in one of the two desired positions (high
or low) and secure in place with the hex screws and flat washers.
See Figure 3-1.
Hex Screw
Flat Washer
High
Low
Figure 3-1
Adjusting the Seat
To adjust the position of the seat, lift the seat adjustment lever
up. Slide the seat forward or rearward to the desired position;
then release the adjustment lever. Make sure seat is locked into
position before operating the rider. See Figure 3-2.
Figure 3-2
NOTE: In order to have the seat tilted up, the seat must be
positioned all the way to the rear. Caution should be used to
avoid damage to the battery cover when tilting the seat forward.
