Cub Cadet RZT-S User Manual

10 Section 3— ASSembly & Set-Up
Steering Wheel
 Remove the hardware for attaching the steering wheel
from beneath the steering wheel cap. Carefully pry off the
steering wheel cover to remove the hardware.
2. With the wheels of the tractor pointing straight forward,
place the steering wheel over the steering shaft.
 Place the flat washer and belleville washer over the steering

Steering Wheel Cover
Hex Screw
Steering Wheel
Steering Wheel
Column
Belleville Washer
Figure 3-3
4. Place the steering wheel cover over the center of the steering

Install Operator’s Seat
To install the seat proceed as follows:
NOTE: The seat is shipped with the seat switch and seat pan
attached. A second person may be needed to hold the seat.
 Cut any straps securing the seat assembly to the tractor.
Remove any packing material.
NOTE: 
seat and the seat switch in the bottom of the seat.
2. Remove the two shoulder screws in the seat pan as shown

Figure 3-4
 Rotate the seat into position and secure the seat into place

not to crimp or damage the wire harness while installing

Figure 3-5
NOTE: 
the seat box hole before continuing.

Cub Cadet RZT-S Specifications

General

Turning Radius	Zero-Turn
Deck Material	Steel
Engine	Kohler
Horsepower	22 HP
Cutting Width	50 in
Transmission	Hydrostatic
Fuel Capacity	3.5 gal
Speed	7 mph
Weight	600 lbs
