Indicator Panel Features
Illuminates and the battery voltage is displayed briefly when the
Illuminates to indicate the battery voltage has dropped below
the hour meter. If this indicator and display come on during
operation, check the battery and charging system for possible
causes and/or contact your Cub Cadet dealer.
This warning lamp indicates low engine oil pressure. If the
indicator comes on while the engine is running, stop the engine
immediately and check for possible causes. Do not run the
engine while this indicator is illuminated. Contact your Cub
Cadet dealer to have the tractor and engine inspected.
NOTE: The oil pressure indicator may illuminate when the
the engine is started.
This indicator illuminates when the parking brake is in the
move the parking brake to the ENGAGED position.
This indicator also illuminates when the ignition switch is turned
are in a position other than the fully out in neutral position. Move
the control levers fully outward.
Throttle Control
a uniform engine speed will be maintained.
the engine speed. The tractor is designed to operate
with the throttle control in the fast position (full
throttle) when the tractor is being driven and the
mower deck is engaged.
the engine speed.
Choke Control
The choke knob controls the position of the
engine; push the knob in to open the choke.
Parking Brake Engagement Lever
The parking brake engagement lever is located on the
front/left of the seat box frame, and is used to engage the
parking brake.
lower completely to disengage the parking brake.
NOTE:
opened out in the neutral position when engaging the
parking brake, the engine will stop. The parking brake
must be placed in the engaged position when starting the
tractor engine.
Transmission Oil Expansion Reservoir
The transmission oil expansion reservoir is connected by hoses to
the seat box. The function of the reservoir is to hold the natural
expansion of transmission oil that occurs as the transmission
Under normal operating conditions, no oil should be added
approximately ⁄
reservoir.
NOTE:
the reservoir may be slightly higher than the maximum due to air
air from the lines and the oil level will settle to the maximum.
13se c t i O n 4 — cO n t r O l s a n d fe a t u r e s
