Deck Lift
NOTE:
position on the tractor when facing forward while seated in the
Deck Height Index
The deck height index consists of six index notches
located on the front/right of the seat box frame. Each
notch corresponds to a ⁄ change in the deck height
⁄
the highest notch.
Deck Lift Handle
The deck lift handle is located on the front/right of the
seat box frame, and is used to raise and lower the mower
deck.
downward to lower the deck, or pull upward to raise the
deck. When the desired height is attained, move the lift
handle to the right until fully in the index notch.
RH and LH Drive Control Levers
space to permit the operator to either sit in the tractor seat, or to
dismount the tractor. The levers must be fully opened out and in
the neutral position to start the tractor engine.
Consequently, these levers control all of the movements of the
tractor. Driving and steering utilizing these control levers is
quite different from conventional tractors, and will take some
the control levers.
Controls and Features
4
