9
SPECIFICATIONS
GENERAL INFO.
Controls: Engine ignition and start switch; throttle; choke; speed control pedals;
electric blade clutch switch; parking brake; mower deck lift
Steering: 14” diameter steering wheel coupled to hydraulic steering valve and
cylinder
Parking Brake: Mechanical linkage brake to internal drum brakes
Seat: Adjustable seat and armrests. 7" Adjustment (fore-aft)
Frame: 2" Steel structural tube and plate, all welded construction
Instrumentation Hour meter, Tachometer, Maintenance-minder
Front Wheels: 60”, & 72” deck, 15 x 7.50 - 8
Drive Wheels: 60", & 72” deck, 24 x 12 - 12
Tire Pressure: 10-12 psi Rear, 20-25 psi Front
Fuel Tank: Two 6.5 gallon w/individual shutoff valves
Ground Speed: 0-12 + MPH forward. 0-5 MPH reverse
Net Weight: 1470 lbs. w/60" deck, 1540 lbs w/72” deck
ENGINE INFO.
Engine: 31HP Kawasaki w/ 60” deck, 31 & 37 HP Kawasaki w/ 72” deck
Type: Vertical crankshaft air cooled V-Twin
Air Cleaner: Dual Paper Element with rain cap
Lube System: Pressurized with oil filter
Hydraulic System: In tank filter, 4 quart capacity, aluminum oil cooler w/ 12VDC fan
Starter: 12-volt electric
Blade Brake Clutch: Electric
TRACTION DRIVE
INFO.
Traction Drive: Engine to two variable-output hydraulic pumps each connected to indi-
vidual wheel motors
CUTTER DECK INFO.
Cutter Deck;Drive: 60", & 72” Belt Driven with Reconfigurable features
Deck Lift: Hydraulic w/pin lock for height adjustment
Cutting Height: 1" to 5" in 1/4” increments
No. of Blades 3, belt-driven, power take-off from engine
