Subframe
Ref.
No.
Part
Number Description Qty.
1 603-04420 Shaft, Deck Subframe 2
2 603-04421 Arm, Front Lift RH 1
3 603-04422 Arm, Front Lift LH 1
4 603-04423A Rail, Subframe LH 1
5 603-04424A Rail, Subframe RH 1
6 603-04425 Arm, Rear Lift RH 1
7 603-04426 Shaft, Rear Lift 2
8 603-04427 Arm, Rear Lift LH 1
9 603-04440 Bracket, Loader Adapter LH 1
10 603-04441 Bracket, Loader Adapter RH 1
11 703-06026 Bracket, Subframe Mounting LH 1
12 703-06027 Bracket, Subframe Mounting RH 1
13 703-06095 Bracket, Lock Pin 2
14 703-06162 Bracket, Breakaway Lift RH 1
15 703-06163 Bracket, Breakaway Lift LH 1
16 703-06164 Bracket, Lift LH 1
17 703-06165 Bracket, Lift RH 1
18 703-06201 Cover, Mid PTO 1
19 710-04129 Screw, Hex Cap, 5/8-11 x 2.5 2
20 710-04697 Screw, Hex Cap, M16-2.0 x 35 4
21 710-04700 Screw, Hex Cap, M16-2.0 x 60 4
22 710-04706 Screw, Hex Cap, 5/8-11 x 1.75 Gr8 2
23 710-04712 Screw, Hex Cap, 3/8-16 x 1.25 Gr2 2
24 710-3005 Screw, Hex Cap, 3/8-16 x 1.25 Gr5 8
Ref.
No.
Part
Number Description Qty.
25 710-3144 Screw, Hex Cap, 3/8-16 x 2.0 Gr5 4
26 711-04845 Pin, .625 Dia. 2
27 712-0261 Nut, Jam Lock, 5/8-16 GrA 2
28 712-04065 Nut, Hex Flange Insert Lock
3/8-16 GrF
10
29 712-3016 Nut, Hex Insert Lock, 5/8-11 Gr5 2
30 712-3056 Nut, Hex Jam, 5/8-18 Gr5 4
31 714-04003 Pin, Internal Cotter, .125 x 2.5 Lg 4
32 714-0474 Pin, Cotter, .125 x .75 2
33 723-04050 Ball Joint, .625 ID x 5/8-18 4
34 723-04061
Ball Joint, .625 ID x 5/8-18 LH
Thrd. 4
35 732-0306A Spring, Compression, .531 x 1.75 2
36 736-0140 Washer, Flat, .385 x .62 x .063 2
37 736-0290 Washer, Flat, .625 x 1.0 x .067 HT 2
38 736-0366 Washer, Flat, .64 x 1.12 x .125 8
39 737-04091 Fitting, Lube 2
40 737-3000 Fitting, Lube 2
41 741-0558 Bearing, Flange, 1.0 x 1.125 x 1.62 8
42 747-04702 Rod, Deck Release 2
43 747-04831 Rod, 23.735 Lg LH/RH Thrd. 2
44 747-04832 Rod, 15.25 Lg LH/RH Thrd. 2
45 750-04858 Spacer, .625 x 4.95 2
46 750-04877 Spacer, 1.25 x .625 2
47 750-04878A Spacer, 1.25 x 1.25 2
To Next Page
