Cub Cadet Yanmar 59A40009727 User Manual

Ref.
No.
Part
Number Description Qty.
1 603-04413 Bracket, Deck Wheel 2
2 603-04416 Deck Housing 1
3 603-04418 Handle, Wheel Height Adjustment 1
4 603-04419 Bracket, Caster Wheel Yoke 2
5 603-04430 Link, Front Lift 2
6 603-0662 Guard, Deck 1
7 603-0848A Bracket, Idler 1
8 918-3129C Spindle Assembly 3
9 638-04012A Bolt Assembly, Shoulder 1
10 703-05658 Plate, Idler Support 1
11 703-06199 Cover, Belt RH 1
12 703-3248 Baffle, Deck 1
13 703-3250 Bracket, Chute Deflector 1
14 703-3273 Cover, Belt LH 1
15 710-0347 Screw, Hex Cap, 3/8-16 x 1.75 Gr5 1
16 710-0376 Screw, Hex Cap, 5/16-18 x 1/0 Gr5 6
17 710-0395 Screw, Hx Cap, 5/16-18 x 2.25 Gr5 1
18 710-0521 Screw, Hex Cap, 3/8-16 x 3.0 Gr8 1
19 710-0805 Screw, Hex Cap, 5/16-18 x 1.5 Gr5 4
20 710-1260A Screw, Hex Wash. Hd Tapp
5/16-18 x .75
12
21 710-1336A Bolt, Spindle, 3/4-16 x 4.25 3
22 710-1638 Screw, Carriage, 1/2-13 x 4.5 Gr5 4
23 710-1649 Screw, Carriage, 3/8-16 x 4.25 Gr5 2
24 710-1880 Screw, Hx Patch, 5/16-18 x .75 Gr5 4
25 710-3168 Bolt, Carriage, 3/8-16 x 1.0 2
26 710-3178 Bolt, Carriage, 3/8-16 x .75 6
27 710-3251 Screw, Socket Hd,
5/16-18 x 1.75 Gr5
1
28 711-04715 Pin, Clevis, .625 x 1.5 4
29 711-04729A Shaft, Gauge Wheel 2
30 711-0679A Pin, Clevis, 3/8 x 2.015 3
31 711-1643 Pin, Clevis, 3/4 x 2.5 2
32 711-3314 Pin, Roller, 1/2 x 7.31 1
33 712-0290 Nut, Hex Lock, 7/16-14 1
34 712-04063 Nut, Hex Insert Flange Lock,
5/16-18 GrF
4
35 712-04065 Nut, Hex Insert Flange Lock,
3/8-16 GrF
5
36 712-0429 Nut, Hex Insert Lock, 5/16-18 Gr5 1
37 712-0431 Nut, Hex Flange Lock, 3/8-16 GrF 7
38 712-0641 Nut, Hex, M16 - 1.5 2
39 712-3046 Nut, Hex Jam Lock, 5/16-18 2
40 712-3078 Nut, Hex Flange Lock, 3/4-16 Gr8 2
41 712-3083 Nut, Hex Insert Lock, 1/2-13 GrB 4
Ref.
No.
Part
Number Description Qty.
42 714-0115 Pin, Cotter, 1/8 x 1.0 1
43 714-0117 Pin, Internal Cotter 2
44 714-0128 Key, Square, 1/4 x 1.0 1
45 714-0147 Pin, Internal Cotter 3
46 714-04003 Pin, Internal Cotter 4
47 716-0102 Ring, Snap 1
48 716-0111 Ring, External Retaining 1
49 717-04415 Gearbox 1
50 717-04422 Shaft, Deck Drive 1
51 721-04041 Adapter, Nozzle 1
52 726-0211 Nut, Speed, 5/16-18 5
53 726-3045 Button, Plug 2
54 731-3005 Roller, Front 1
55 731-3257 Deflector, Chute 1
56 732-0850 Spring, Extension, 1.0 x 6.14 1
57 732-0939 Spring, Torsion 1
58 734-04314 Wheel, Caste 4
59 736-0258 Washer, Flat, .385 x 1.0 x .135 2
60 736-0275 Washer, Flat, .344 x .688 x .065 1
61 736-0291 Washer, Flat, .88 x 1.38 x .125 HT 1
62 736-0322 Washer, Flat, .45 x 1.25 x .164 HT 1
63 736-0354 Washer, Flat, .39 x .75 x .105 1
64 736-0362 Washer, Flat, .33 x 1.25 x .06 HT 1
65 736-04167 Washer, Flat, 1.063 x 2.5 x .16 1
66 736-0760 Washer, Lock 1
67 737-04003C Nozzle, Deck Wash 2
68 737-3000 Fitting, Lube 3
69 738-03056 Bolt, Shoulder, .496 x 2.5:3/8-16 1
70 741-0941 Bearing, Ball 2
71 759-04013 Blade, High Lift 3
72 747-3384 Rod, Chute Deflector 1
73 748-3065A Spacer, Spindle 6
74 748-3087 Spacer, Idler 1
75 750-0535 Spacer, .38 x .625 x .21 1
76 750-3222 Axle, Caster Wheel 4
77 754-3103 V Belt, B Section x 133 1
78 756-04292 Pulley, Drive 1
79 756-3062 Pulley, Idler 5.0 2
80 756-3096 Pulley, Spindle 3
81 721-3018A Seal, Oil 6
82 741-04129 Bearing, Cone 6
83 741-04130 Cup, Bearing 6
84 750-04409 Spacer, Bearing 3
Mower Deck
