Fig 7. Camshaft & Driving Gear
Ref.
Part Number Description Qty
1 CY-129150 -14200 TAPPET 8
2 CY-129150 -14400 ROD, PUSH 8
3 CY-729402-14580 CAMSHAFT ASSY 1
4 CY-129150-02450 METAL, THRUST 1
6 CY-129150 -14101 GEAR, CAMSHAFT 1
7 CY-22512-070140 KEY, 7X14 1
8 CY-26106-080142 BOLT 8X 14 PLATED 2
9 CY-119803-25050 SHAFT, IDLER 1
10 CY-119802-25101 GEAR ASSY, IDLE 1
13 CY-26106-080402 BOLT M 8X 40 PLATED 3
14 CY-129150-25301 BOLT, PUMP 4
15 CY-119802-25901 GEAR, PUMP 1
16 CY-129150 -01881 GASKET, COVER 1
17 CY-129150-26000 DRIVE ASSY, PUMP 1
18 CY-129150-26050 BRACKET, PUMP 1
20 CY-24105-060064 BALL BEARING 2
21 CY-119802-25071 BUSH, IDLE GEAR 1
