Fig 10. Lub. Oil System
Ref.
Part Number Description Qty
1 CY-129407-32000 PUMP ASSY, LUB.OIL 1
14 CY-129150-32020 GASKET, PUMP 1
15 CY-26450-060252 BOLT, M6X25 4
16 CY-129468-34810 GUIDE, DIPSTICK 1
17 CY-129558-34820 DIPSTICK, LUB.OIL 1
18 CY-129150-35042 GASKET, PIPE 1
19 CY-129550-35090 PIPE ASSY, OIL INLET 1
24 CY-26106-080122 BOLT M 8X 12 PLATED 1
25 CY-26106-080352 BOLT M 8X 35 PLATED 2
26 CY-119802-35100 BRACKET ASSY, FILTER 1
27 CY-119802-35110 BRACKET, FILTER 1
28 CY-129100-35140 STUD 1
29 C Y-12 915 0 - 35111 GASKET, BRACKET 1
31 CY-26106-080202 BOLT M 8X 20 PLATED 3
32 CY-114250-39450 SWITCH, OIL PRESSURE 1
33 CY-124160-39140 BOLT, JOINT M10 1
34 CY-119802-39450 PIPE ASSY, LUB.OIL 1
35 CY-129005-59830 BOLT ASSY, JOINT 1
36 CY-22190-080002 SEAL WASHER 8S 1
37 CY-23857-030000 JOINT BOLT 3 1
38 CY-22190-080002 SEAL WASHER 8S 1
39 CY-22190-100002 WASHER, 10 2
40 CY-26366-060002 NUT M 6 1
41 CY-129150-35153 FILTER 80X80L 1
