Fig 17. Starting Motor
Ref.
Part Number Description Qty
1 CY-129407-77010 STARTER, RA1.4 1
2 CY-X0283060061 ROLLER 5
3 CY-X9490561370 NUT 1
4 CY-X9491200240 BALL 1
5 CY-124795-77210 YOKE 1
6 CY-129407-77220 ARMATURE ASSY 1
7 CY-129129-77230 BEARING 1
8 CY-129129-77240 BEARING 1
9 CY-129407-77250 STARTER 1
10 CY-X0280210230 NUT 1
11 CY-X0283270140 RETAINER, SNAP 1
12 CY-129407-77390 CLUTCH ASSY, STARTER 1
13 CY-129129-77440 BALL BEARING 1
14 CY-129129 -77450 BALL BEARING 1
15 CY-129129-77400 SHAFT 1
16 CY-129129-77410 SPRING, COIL 1
17 CY-X9 491703371 SPRING, COIL 1
18 CY-129129-77420 PINION, STARTER 1
19 CY-129129 -77430 RING, SNAP 1
20 CY-129129 -77260 RETAINER 1
21 CY-129129-77270 PINION 1
22 CY-129407-77280 HOUSING 1
23 CY-129407-77290 FRAME 1
24 CY-129407-77300 HOLDER ASSY 1
25 CY-X9491730 461 SPRING 4
26 CY-129407-77310 SWITCH ASSY 1
27 CY-129129 -77320 BOLT 2
28 CY-129407-77330 BOLT 2
29 CY-129129 -77340 SPRING 1
30 CY-129129-77350 O-RING 2
31 CY-129129 -77362 COVER 1
33 CY-129129 -77380 CAP 1
34 CY-129129 -77460 SCREW 2
35 C Y-26116 -12 02 52 BOLT M12X 25 PLATED 2
