Fig 3. Engine Accessories Lx410 & Lx450
Ref.
Part Number Description Qty
1 CY-1A7140-00600 RADIATOR ASSY 1
2 CY-1A7180-01050 RUBBER,RADIATOR 2
3 CY-1A8250-01210 TUBE,COOLING WATER A 1
4 CY-1A7260 -01220 PIPE, COOLING WATER 1
5 CY-1A8250-01250 SCREEN, RADIATOR 1
6 CY-194150-01270 SPACER 20 1
7 CY-1A8250-01500 SHROUD M ASSY, FAN 1
8 CY-198280-04470 JOINT 1
9 CY-1A8240-04620 CLAMP, FUEL HOSE 1
10 CY-1A8240-05100 CLEANER ASSY,5.5IN,D 1
11 CY-1A8240-05110 ELEMENT ASSY, OUTER 1
12 CY-1A8240-05120 ELEMENT ASSY, INNER 1
13 CY-1A8240-05130 GASKET, AIR CLEANER 1
14 CY-1A8240-05150 BODY, 1
15 CY-1A8240-05160 COVER ASSY 1
16 CY-1A8240-05170 VALVE, UNLOADER 1
17 CY-1A8240-05180 CLIP NUT, M8 2
18 CY-1A8275-05510 PLATE,SHUTTER,88 ASS 1
19 CY-1A8240-05810 COVER, BELT L 1
20 CY-1A8240-05820 COVER, BELT R 1
21 CY-1A8240-06200 PIPE A, INTAKE 1
22 CY-1A8240-06220 HOSE B, INTAKE 1
23 CY-1A8240-15460 BRACKET, CLAMP 1
24 CY-194990 -22140 NUT W/WASHER 8 2
25 CY-194990-22140 NUT W/WASHER 8 2
26 CY-198220-37900 PIN 8X24 1
Ref.
Part Number Description Qty
27 CY-121750-49150 PIPE, C. WATER 1
28 CY-175022-49750 CLIP 37, HOSE 2
29 CY-194440-51620 CLAMP, WIRE HARNESS 1
30 CY-194680-51670 BAND 2
31 CY-194680-51670 BAND 1
32 CY-1A7601-53920 URETHANE,SIDE LAMP 1
33 CY-114270-59010 CLIP, HOSE 2
34 CY-114270-59010 CLIP, HOSE 4
35 CY-114270-59010 CLIP, HOSE 2
36 CY-1A8240-60220 SUPPORT, CLEANER 1
37 CY-23000-035000 CLAMP 35 2
38 CY-23000-070000 CLAMP 70 2
39 CY-23000-070000 CLAMP 70 1
40 CY-23980-730200 HOSE 7.3X200,BRAIDED 1
41 CY-23980-730400 FUEL PIPE 7.3X400 2
42 CY-23980-730600 FUEL PIPE 7.3X600 1
43 CY-26106-060202 BOLT M 6X 20 PLATED 4
44 CY-26106-080122 BOLT M 8X 12 PLATED 2
45 CY-26106-080162 BOLT M 8X 16 PLATED 2
46 CY-26106-080162 BOLT M 8X 16 PLATED 3
47 CY-26106-080162 BOLT M 8X 16 PLATED 1
48 CY-26106-080302 BOLT M 8X 30 PLATED 2
49 CY-26106-100202 BOLT M10X 20 PLATED 1
50 CY-198071-61890 NUT 6,SPEED 1
51 CY-26106-060202 BOLT M 6X 20 PLATED 1
