Lx450Lx Series
42
Copyright 2011 Cub Cadet Yanmar LLC
Fig 5. Grommet
Ref.
Part Number Description Qty
1 CY-194180 - 61980 GROMMET 24 1
Fig.5. GROMMET
0CNP5-G37900
0CNP5-G37900
5. GROMMET
(F)=
(E)=
(D)=
(C)=LX490
(B)=LX450
(A)=LX410
LEV.REF. PARTS NO. DESCRIPTION
RI
Q'TY
(F)(D)(C)(B)(A) (E)
GROMMET 24194180-6198011 111
(C)Copy Rights YANMAR CO.,LTD.
