Cub Cadet Yanmar Lx490 - Page 141

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
141
Fig 75. Hyd. Cylinder Housing
Ref.
Part Number Description Qty
1 CY-192167-24600 PLUG 1
2 CY-1A8275-42100 HOUSING ASSY, 1
3 CY-23871-010000 PLUG PT1/8,SCREW 2
4 CY-1A7180 -42281 PIPE, BREATHER 1
5 CY-1A8275-42810 HINGE, P TOP LINK 1
6 CY-1A8275-43100 HEAD ASSY,CYLINDER 1
7 CY-23871-010000 PLUG PT1/8,SCREW 4
8 CY-1A7640-43450 PLUG, CHECK VALVE 1
9 CY-194555-46380 SPRING 1
10 CY-24190 -130003 STEEL BALL 1
11 CY-24315-000140 O-RING 1B P-14.0 3
12 CY-24315-000140 O-RING 1B P-14.0 1
13 CY-24315-000180 O-RING 1B P-18.0 1
14 CY-24325-000800 O-RING, 1B G 80.0 1
15 CY-26106-120302 BOLT M12X 30 PLATED 5
16 CY-26106-120302 BOLT M12X 30 PLATED 6
17 CY-26106-120502 BOLT M12X50 1
