Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
147
Fig 78. Lift Crank
Ref.
Part Number Description Qty
1 CY-1A7180 -44210 SHAFT,LIFT 1
2 CY-1A7640-44230 WASHER, 65X82X2 2
3 CY-1A7640-44240 SEAL PLATE 2
4 CY-194640-44250 SLEEVE, LIFT SHAFT 2
5 CY-194640-44261 SEAL, SPLINE SHAFT 2
6 C Y-1A 718 0 - 4 4311 CRANK CMP,LIFT 1
7 CY-1A7180 -43410 ROD,PISTON 1
8 CY-1A7180 -44110 CRANK,LIFT 1
9 CY-22351-050070 SPRING PIN 5X70 1
10 CY-22351-080070 SPRING PIN 8X70 1
11 CY-1A7180444101 ARM,LIFT 2
12 CY-1A8275-44510 PLATE, P FEEDBACK 1
13 CY-194640-44540 RETAINER 1
14 CY-22351-060016 SPRING PIN 6X16 1
15 CY-22417-200200 COTTER PIN 2.0X20 1
16 CY-24311-000360 O-RING 1A P-36.0 1
17 CY-24321-000650 O-RING 1A G-65.0 4
18 CY-26106-120302 BOLT M12X 30 PLATED 2
