Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
15
Fig 6. Exhaust Manifold & Muer
Ref.
Part Number Description Qty
1 CY-129550 -13110 GASKET, EXH.MANIFOLD 1
2 CY-129558-13120 MANIFOLD, EXHAUST 1
3 CY-119802-13630 BOLT, M8X55 8
4 CY-129418-18320 STUD, M8X20 4
5 CY-129558-13300 BEND, EXHAUST 1
6 CY-129558-13310 STIFFENER,EXH. BEND 1
7 CY-129558-13530 SILENCER 1
8 CY-129107-13550 GASKET, NOZZLE 1
9 CY-119802-13630 BOLT, M8X55 2
10 CY-129659-13660 STAY, SILENCER 1
11 CY-129508-18090 GASKET, TURBINE OUT 1
12 CY-119131-18320 STUD, M8X22 3
13 CY-26014-080222 BOLT M 8X 22 2
14 CY-26014-080252 BOLT M 8X 25 2
15 CY-26106-080162 BOLT M 8X 16 PLATED 2
16 CY-26106-080302 BOLT M 8X 30 PLATED 2
17 CY-26306-080002 NUT, M8 3
