Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
155
Fig 83. Loader Valve
Ref.
Part Number Description Qty
1 CY-194990-22140 NUT W/WASHER 8 2
2 CY-194990-22140 NUT W/WASHER 8 1
3 CY-1A8160 -46250 COUPLER,QUICK 3/8F 4
4 CY-1A8160-46280 PLUG, DUST RED 1
5 CY-1A8160 -46290 PLUG, DUST BLUE 1
6 CY-1A8160 -46300 PLUG, DUST YELLOW 1
7 CY-1A8160-46310 PLUG, DUST GREEN 1
8 CY-1A8250-46600 SCV ASSY, 1
9 CY-1A8250-46750 SUPPORT ASSY, VALVE 1
10 CY-1A8250-46801 SUPPORT, 1
11 CY-1A8250-48200 ELBOW/HYD, 3/4UNF-L 2
12 CY-194464-45930 O-RING 8-1 2
13 CY-1A8250-48210 ELBOW/HYD, 3/4UNF 2
14 CY-194464-45930 O-RING 8-1 2
15 CY-1A8250-48220 JOINT/HYD,3/4UNF-3/8 4
16 CY-194464- 45930 O-RING 8-1 4
17 CY-1A8250-48350 FITTING/HYD, 3/4-7/8 1
18 CY-194464-45930 O-RING 8-1 1
19 CY-26106-080122 BOLT M 8X 12 PLATED 3
20 CY-26106-080202 BOLT M 8X 20 PLATED 1
