Cub Cadet Yanmar Lx490

Lx490Lx Series
156
Copyright 2011 Cub Cadet Yanmar LLC
Fig 84. Breather
Ref.
Part Number Description Qty
1 CY-194440-51620 CLAMP, WIRE HARNESS 1
2 CY-194640-63560 PIPE, AIR BREATHER 1
Fig.84. BREATHER
0CNP5-G37900
0CNP5-G37900
84. BREATHER
(F)=
(E)=
(D)=
(C)=LX490
(B)=LX450
(A)=LX410
LEV.REF. PARTS NO. DESCRIPTION
RI
Q'TY
(F)(D)(C)(B)(A) (E)
CLAMP, WIRE HARNESS194440-5162011 111
PIPE, AIR BREATHER194640-6356012 111
(C)Copy Rights YANMAR CO.,LTD.
