Fig 87. Hydraulic Control
Ref.
Part Number Description Qty
1 CY-1A8275-47160 PLATE 1
2 CY-1A8275-47250 ARM, LEVER P 1
3 CY-1A8275-47330 CONTROL PLATE 1
4 CY-194555-47340 PLATE (A) 1
5 CY-194555-47350 PLATE 1
6 CY-1A8275-47350 BOLT, FRICTION 1
7 CY-1A8275-47370 ARM,P CONTROL F.BACK 1
8 CY-1A8275-47420 BAR, P CONTROL 1
9 CY-194170-47440 PLATE, FRICTION 1
10 CY-1A8275-47440 PLATE 1
11 CY-1A8275-47450 ARM, 1
12 CY-198200- 47460 ROD, CONTROL 1
13 CY-1A8275-47500 ARM,P CONTROL 1
14 CY-194550 -47530 ADJUSTER 1
15 CY-194640-47550 ROD, ASSY, P 1
16 CY-194640 -47560 ROD, FEED BACK 1
17 CY-26716-100002 NUT 10 1
18 CY-1A8275-47550 SHAFT, P LEVER 1
19 CY-1A8275-47630 COLLAR, P LEVER 2
20 CY-194151-47760 WASHER 12 4
21 CY-22137-100000 WASHER 10,POLISHED 1
22 CY-22137-100000 WASHER 10,POLISHED 1
23 CY-22137-120000 WASHER 12,POLISHED 2
24 CY-22272-000070 CIRCLIP E- 7 1
25 CY-22351-050025 SPRING PIN 5X25 1
26 CY-22351-050025 SPRING PIN 5X25 1
27 CY-22417-200200 COTTER PIN 2.0X20 1
28 CY-22487-080200 PIN, H8X20 1
29 CY-22522-030130 KEY, WOODRUFF 3X13 1
30 CY-24311-000150 O-RING 1A P-15.0 1
31 CY-24311-000150 O-RING 1A P-15.0 1
32 CY-26106-080162 BOLT M 8X 16 PLATED 1
33 CY-26106-080162 BOLT M 8X 16 PLATED 2
34 CY-26106-080602 BOLT M 8X 60 PLATED 2
35 CY-26716-100002 NUT 10 1
36 CY-26736-160002 NUT M16 1
