Fig 88. Hydraulic Operation 2
Ref.
Part Number Description Qty
1 CY-1A8250-46640 KNOB, STOP VALVE 1
2 CY-26106-060402 BOLT M 6X 40 PLATED 1
Fig.88. HYDRAULIC OPERATION(2
0CNP5-G37900
0CNP5-G37900
88. HYDRAULIC OPERATION(2
(F)=
(E)=
(D)=
(C)=LX490
(B)=LX450
(A)=LX410
LEV.REF. PARTS NO. DESCRIPTION
RI
Q'TY
(F)(D)(C)(B)(A) (E)
KNOB, STOP VALVE1A8250-4664011 111
BOLT M 6X 40 PLATED26106-06040212 111
