Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-194990-22140 NUT W/WASHER 8 2
2 CY-1A8240-47330 LEVER ASSY, LIFT 1
3 CY-198010-47340 PIPE, PROTECTOR 1
4 CY-198200- 47810 KNOB, BLACK 1
Copyright 2011 Cub Cadet Yanmar LLC
163
Fig 89. Lift Lever
Fig.89. LIFT LEVER
0CNP5-G37900
0CNP5-G37900
89. LIFT LEVER
(F)=
(E)=
(D)=
(C)=LX490
(B)=LX450
(A)=LX410
LEV.REF. PARTS NO. DESCRIPTION
RI
Q'TY
(F)(D)(C)(B)(A) (E)
NUT W/WASHER 8194990-2214011 222
LEVER ASSY, LIFT1A8240-4733012 111
PIPE, PROTECTOR198010-4734013 111
KNOB, BLACK198200-4781014 111
(C)Copy Rights YANMAR CO.,LTD.
