Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
183
Fig 104. Front Lamp
Ref.
Part Number Description Qty
1 CY-194990-22130 NUT W/WASHER 6 2
2 CY-1A7180-51310 HARNES, HEAD 1
3 CY-1A8070-53010 LAMP ASSY, SIDE L 1
4 CY-1C6860-08160 SOCKET ASSY, 1
5 CY-1A8070-53030 CASE ASSY,SIDELAMP L 1
6 CY-1A7260-53220 CAP 1
7 CY-1C6980-08150 BULB,12V/18W 1
8 CY-1A8070-53020 LAMP ASSY, SIDE R 1
9 CY-1C6860-08160 SOCKET ASSY, 1
10 CY-1A8070-53040 CASE ASSY,SIDELAMP R 1
11 CY-1A7260-53220 CAP 1
12 CY-1C6980-08150 BULB,12V/18W 1
13 CY-1A8265-53050 STAY ASSY, HEADLAMP 1
14 CY-1A8280-53200 LAMP, HEAD L CMP 1
15 CY-1A8280-53220 BULV,55W/60W 1
16 CY-1A8280-53300 LAMP, HEAD R CMP 1
17 CY-1A8280-53220 BULV,55W/60W 1
18 CY-194420-61640 SCREW 5X16 6
19 CY-26106-060202 BOLT M 6X 20 PLATED 4
20 CY-26106-080122 BOLT M 8X 12 PLATED 3
