Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-1A7870-52950 RELAY, (CB 1
2 CY-1A7870-52950 RELAY, (CB 1
3 CY-1A7870-52950 RELAY, (CB 1
4 CY-1A8275-57100 RELAY-UNIT 1
5 CY-1A6780-57200 FLUSHER UNIT 1
6 CY-26106-060122 BOLT M 6X 12 PLATED 3
7 CY-26106-060122 BOLT M 6X 12 PLATED 1
8 CY-26106-060202 BOLT M 6X 20 PLATED 2
Copyright 2011 Cub Cadet Yanmar LLC
185
Fig 106. Relay
Fig.106. RELAY
0CNP5-G37900
0CNP5-G37900
106. RELAY
(F)=
(E)=
(D)=
(C)=LX490
(B)=LX450
(A)=LX410
LEV.REF. PARTS NO. DESCRIPTION
RI
Q'TY
(F)(D)(C)(B)(A) (E)
RELAY, (CB1A7870-5295011 111
RELAY, (CB1A7870-5295012 111
RELAY, (CB1A7870-5295013 111
RELAY-UNIT1A8275-5710014 111
FLUSHER UNIT1A6780-5720015 111
BOLT M 6X 12 PLATED26106-06012216 333
BOLT M 6X 12 PLATED26106-06012217 111
BOLT M 6X 20 PLATED26106-06020218 222
(C)Copy Rights YANMAR CO.,LTD.
